Style 9900
Product Code: Style-9900
Technical Data Sheet
Benefits
Heat and oxidation resistance
- Graphite fiber gasketing withstands extreme temperatures and pressures, as well as many chemicals
- Passed Garlock Fire tests, and is ABS Fire Safe Type Approved
Long-lasting seal
- Unique manufacturing process minimizes cold flow and creep relaxation problems
Versatile
- Ideal for standard ANSI flanged connectors, as well as turbine crossover piping connectors
- Multiple applications in power generation, chemical processing, hydrocarbon processing, and other industries
Media
- Steam*, oils, grease, water, heat transfer fluids+
+Contact Hanna Rubber Company with specific transfer fluid application.
*Minimum recommended assembly stress = 4,800psi. Preferred assembly stress = 6,000-10,000psi. Gasket thickness of 1/16″ strongly preferred. Retorque the bolts/studs prior to pressurizing the assembly. For saturated steam above 150psig…
Additional information
| Min. Temperature | -100°F (-73°C) |
|---|---|
| Continuous Max | +650°F (+343°C) |
| Max Temperature | +1000°F (+537°C) |
| Max Pressure | 2000 psig (138 bar) |
| Maximum PxT 1/16: | 700,000 (°F x PSIG) |
| Maximum PxT 1/8 | 350,000 (°F x PSIG) |
| ASTM F104 | F712102A9B3E22K9L401M5(4) |
