        Product Code: Style-HP3560

        Technical Data Sheet

        Benefits
        Tight seal

        • Perforated stainless steel core increases resistance to pressure fluctuations and thermal cycling
        • GYLON® offers superior cold flow and creep resistance, eliminating the need for frequent retorquing

        Chemical resistance

        • Seals aggressive chemicals in hostile environments where safety or blowout resistance is crucial*

        Media

        • Strong acids (except hydrofluoric)
        • Solvents
        • Hydrocarbons
        • Water
        • Steam
        • Chlorine
        • Cryogenics (For oxygen service, specify “HP3562 for oxygen service.”)

        Additional information

        Min. Temperature

        Continuous Max

        +500°F (+260°C)

        Max Pressure

        2500 psig (172 bar)

        Maximum PxT 1/16

        700,000 (°F x PSIG)

        Maximum PxT 1/8

        450,000 (°F x PSIG)

        ASTM F104

        F451999A9B4E99K6M6(3,4)
