Solid Rubber Ribbed Vibration Pads
Product Code: A4694-VIB-PAD
Technical Data Sheet
The A4694 Vibration Pad is specifically designed to isolate vibration. Our solid rubber vibration pad is a two-sided Ribbed Neoprene Pad, 28.75″ x 28.75″ x 3/8″ thick. It has a 3/16″ wide ribs that run at an angle of 90°perpendicular to each other to ensure good grip and anti-vibration properties.
These solid rubber ribbed vibration pads are available for purchase online.
Additional information
| Color | Black |
|---|---|
| Polymer | Neoprene |
| Sheet Size | .375” x 28.75” x 28.75” |
| Weight | 7.0 |
| Hardness (Shore A) | 50 |
| Maximum Temperature (°F) | 180 |
| Minimum Temperature (°F) | -30 |
| Tensile Strength (PSI) | 1200 |
| Elongation at Break (%) | 300 |
| Density (lb./in.³) | .04 |
| Max Load | 50 PSI (Load capacity may be increased by using multiple layers) |
